New V-MAX Pro Series C-Arm Table [EQ-030602]
Standard features for both table models include:
Diving board style for easy C-arm access
Large patient capacity (500-lb pound load)
2” high quality patient comfort pad
Facial cut-out access
A 24” wide carbon fiber top eliminates the needs for arm boards
A 27″ wide top upgrade is also available
An 84″ length to accommodate even the tallest of patients
Easy patient transfer to table
Any OR accessory can be rigidly attached to the table top
Bellows to cover and protect the table motor assembly
Rotating and lockable casters
Control handle (joystick) for easy table movement
The V-MAX and V-MAX T models differ in heights and movements supported:
V-MAX offers Height (28″ to 38″), Lateral Float (14″), and also Longitudinal Float (38″, +/- 19″) adjustments.
V-MAX T offers Height (30″ to 40″), Lateral Float (14″), Longitudinal Float (38″, +/- 19″), and also Trendelenburg (+/- 17°) adjustments.
V-Max Optional adds:
Foot switch
Modular side rail system
Surgical arm boards (can rotate 180 degrees)
Procedural arm boards (each can rotate 180 degrees)
Rectangle arm boards
Lollipop arm boards
Catheter Tray
A Joystick is standard with both V-MAX models.
The height buttons support raising and lowering the table top. The Trendelenburg buttons control the angle of inclination of the head end. The four-way float allows to user to move laterally and longitudinally with the press of one button at the top of the joystick.
Note that all V-MAX Series imaging tables with motorized movements require 120 VAC power for operation
- Manufacturer: Surgical Tables, Inc.
- Modality: C-Arm Table
- Model: V-MAX
- Year of Manufacture: New
