2022 Solutions for Tomorrow !M1 Portable X-ray [A-014972]

2022 Solutions for Tomorrow !M1 Portable X-ray [A-014972]

Total weight 324 kg
Width 580 mm
Length body 1130 mm
Length with handle 1245 mm
Height 1200 mm

Power Supply
Power supply rating 800 VA
Voltage 100 - 240 VAC (+/- 10%)
Frequency 50/60 Hz

Battery
Type Lithium-Ion
Voltage output Max 200V, 185 Nom
Charging time from 0% to 100%: Approximately 90 min
Operation time: Up to 9 hours (1200 exposures of 100 kV and 10 mAs or 15 km driving)
10 min charging gives 1 hour operation time

High voltage generator
High frequency X-ray generator
Power output Max. 32 kW at 100 mS
Nominal power output N/A
Power supply rating N/A (battery operated)
Current time 0.1 - 320 mAs
Tube voltage setting range 40 - 125 kV (40 - 133 kV as option)

Wifi
Standard IEEE 02.11 b/g/n/ac
Frequency 2.4 GHz, 5 GHz
Transfer speed 1.73 Gbps

X-ray system
kVp value 40 - 125 kVp in 1 kV step (40 - 133 kVp as option)
mA range 13 - 320 mA (13 - 400 as option)
X-ray Tube
Type SFT !M1
Focus size 0.4/1.3 or 0.6/1.3 mm

Image System
Type CS-7 Konica Minolta software
Canon CXDI Control Software NE
PC Intel NUC, i5, 2.3 - 3-8 GHz, 8 GB Ram,

Collimator
Type Manual, single layer
Lamp type LED

Image receptor
Applicable types Digital (DR), Computed radiography (CR), Film
Storage (2x) 17"x17", 14"x17", 10"x12"
Collision protection (front, tube and monitor)

Options
Wireless remote control for exposure and collimator light
Dose Area Meter (integrated inside collimator)
Tube head display: Ipad application and mount (only for Konica Minolta image software)
Keyless entry
Detector lock
Pediatric version: color scheme
