2012 GE Optima XR220 Portable X-ray [A-015525]

2012 GE Optima XR220 Portable X-ray [A-015525]

Nominal Tube Voltage (Radiographic) 40 ~ 150 kV
Nominal Focal Spot size (IEC 60336): Large Focus: 1.2 mm; Small Focus: 0.6 mm
Anode Rotation Speed (minimal): 3200 min-1
Permanent Filtration: 0.9 mm Al/75 kV IEC60522: 1999
Maximum X-ray Tube Current: Large Focus: 500 mA; Small Focus: 200 mA
Maximum Continuous Heat Dissipation: Without Air-circulator: 170 W (238 HU/s)
Maximum anode heat units: 140 kHU
Exposure time: 4.0 msec – 6.0 sec
Capable of 100-240 V nominal, 50/60 Hz operation
System battery status display

Flashpad Detector
Detector battery can take up to 50 exposures per hour and provide enough power for 3 hours of use on a single charge
Single panel (non-tiled) amorphous silicon detector with a Cesium Iodide scintillator
Image area: 40.4 cm x 40.4 cm (15.9 in x15.9 in)
Active matrix: 2024 x 2024 pixels
Pixel Pitch: 200 microns
Typical upper dynamic range: 7.8mR
Typical DQE: @ 0lp/mm: 68%)
Two handgrips
